U24-12XP thumbnail

U24-12XP

The U24-12XP is a high-performance, 12 volt battery, built on a patented Lithium Iron Phosphate chemistry platform providing over 1.5 kWh.

Dimensions (mm): 225 x 172 x 260 | (H x W x L)

Dimensions (inch): 8.86 x 6.77 x 10.23 | (H x W x L)

12.8 V | 118 Ah | 16.3 kg | PN# 1008956

fdsdfs

Certifications

UL 2580 | UL 1642 (cells) | IEC 62619 | FCC Class B, CE | UN 38.3

Shipping Classifications

UN 3480 | Class 9

features

undefined
  • >4000 cycles at 80% DOD
  • Create systems 12 - 1000 V
  • Series and/or parallel operation
  • Automatic cell monitoring & balancing
  • Temperature monitoring of cells
  • Rugged mechanical design
  • Dual lug contacts
  • • Thread locking feature
  • • Footprint of Group 24 lead acid case
  • • Maintenance-free
  • • No hydrogen generation or gassing
