U27-36XP

The U27-36XP is a high-performance, 36 volt battery, built on a lithium iron phosphate chemistry platform providing a safe, reliable and mobile energy solution. Customers now have a choice of a 36 volt battery in a Group 27 size case providing over 1.9 kWh.

Dimensions (mm): 225 x 172 x 306 | (H x W x L)

Dimensions (inch): 8.86 x 6.77 x 12.0 | (H x W x L)

38.4 V | 50 Ah | 18.7 kg | PN# 1008847

Certifications

UL 1642 (cells) | FCC Class B, CE | UN 38.3


Shipping Classifications

UN 3480

Specifications

features

undefined
  • >4000 cycles at 80% DOD
  • Create systems 36 - 1000 V
  • Series and/or parallel operation
  • Automatic cell monitoring & balancing
  • Temperature monitoring of cells
  • Rugged mechanical design
  • Thread locking feature
  • Maintenance-free
  • No hydrogen generation or gassing
